The Analysis Of Irregular Shaped Structures Diaphragms And Shear Walls by Terry R. MaloneThe Analysis Of Irregular Shaped Structures Diaphragms And Shear Walls by Terry R. Malone

The Analysis Of Irregular Shaped Structures Diaphragms And Shear Walls

byTerry R. Malone, Robert W. Rice

Hardcover | November 10, 2011

Pricing and Purchase Info

$154.90 online
$180.95 list price save 14%
Earn 775 plum® points

Prices and offers may vary in store


In stock online

Ships free on orders over $25

Not available in stores


A Complete Guide to Solving Lateral Load Path Problems

The Analysis of Irregular Shaped Structures: Diaphragms and Shear Walls explains how to calculate the forces to be transferred across multiple discontinuities and reflect the design requirements on construction documents. Step-by-step examples offer progressive coverage, from basic to very advanced illustrations of load paths in complicated structures. The book is based on the 2009 International Building Code, ASCE/SEI 7-05, the 2005 Edition of the National Design Specification for Wood Construction, and the 2008 Edition of the Special Design Provisions for Wind and Seismic (SDPWS-08).


  • Code sections and analysis
  • Diaphragm basics
  • Diaphragms with end horizontal offsets
  • Diaphragms with intermediate offsets
  • Diaphragms with openings
  • Open front and cantilever diaphragms
  • Diaphragms with vertical offsets
  • Complex diaphragms with combined openings and offsets
  • Standard shear walls
  • Shear walls with openings
  • Discontinous shear walls
  • Horizontally offset shear walls
  • The portal frame
  • Rigid moment-resisting frame walls--the frame method of analysis

R. Terry Malone, P.E., S.E., performs third-party structural plan reviews and presents structural-related seminars at state and local International Code Council (ICC) chapters. He was a practicing structural engineer in Tacoma, Washington for 17 years, after which he became a principal in consulting structural engineering firms in Wash...
Title:The Analysis Of Irregular Shaped Structures Diaphragms And Shear WallsFormat:HardcoverDimensions:9.5 × 7.7 × 1.33 inPublished:November 10, 2011Publisher:McGraw-Hill EducationLanguage:English

The following ISBNs are associated with this title:

ISBN - 10:007176383X

ISBN - 13:9780071763837

Look for similar items by category:


Table of Contents

Ch. 1. Code Sections and Analysis
Ch. 2. Diaphragm Basics
Ch. 3. Diaphragms With End Horizontal Offsets
Ch. 4. Diaphragms With Intermediate Offsets
Ch. 5. Diaphragms with Openings
Ch. 6. Open Front and Cantilever Diaphragms
Ch. 7. Diaphragms With Vertical Offsets
Ch. 8. Complex Diaphragms With Combined Openings and Offsets
Ch. 9. Standard Shear Walls
Ch. 10. Shear Walls With Openings
Ch. 11. Discontinuous Shear Walls
Ch. 12. Horizontally Offset Shear Walls
Ch. 13. The Portal Frame
Ch. 14. Rigid Moment-Resisting Frame Walls: The Frame Method of Analysis
